Build a Universal XCFramework with a Single Script

Introduction:

XCFrameworks are Apple’s preferred way to distribute binary frameworks, supporting multiple platforms and architectures within a single package. This article walks you through automating the creation of a universal XCFramework using a handy Bash script.

Prerequisites:

• Xcode command-line tools installed
• A working Xcode project with a framework target

Steps:

1. Get the Script: Copy the provided Bash script into a file (e.g., build_xcframework.sh) and save it in your project's root directory.
2. Customize:

• Open build_xcframework.sh in a text editor.
• Replace "YourProjectName" with your actual Xcode project name (without the .xcodeproj extension).
• Replace "YourSchemeName" with your framework's scheme name.
• (Optional) Change the OUTPUT_FOLDER variable to your preferred output location.

1. Run the Script:

• Open your terminal and navigate to your project’s root directory.
• Make the script executable: chmod +x build_xcframework.sh
• Execute the script: ./build_xcframework.sh

1. Check for Success:

• The script will clean, build, archive, and create the XCFramework.
• Find your XCFramework in the specified output folder (e.g., output/<YourSchemeName>.xcframework).

Explanation:

• The script first cleans the build directory to start fresh.
• It then builds your project for both iOS and iOS Simulator destinations, creating separate archives.
• Finally, it combines the archives into a universal XCFramework containing both architectures.

Integrating with Xcode (Optional):

1. In Xcode, go to your target’s “Build Phases” tab.
2. Click “+” to add a “New Run Script Phase.”
3. Paste the Bash script into the script area.
4. Drag the new run script phase above “Copy Bundle Resources” for proper execution order.
5. Now, building your project will automatically create the XCFramework.

Key Points:

• This script assumes a single framework target. Adapt it if you have multiple frameworks.
• Add error checks to the script for better robustness.
• Explore the xcodebuild command's options to further customize your build process.

Let me know if you’d like help adapting this for multiple architectures or integrating it as a build phase script in Xcode by commenting.

#!/bin/bash

# --- Configuration ---
PROJECT_NAME="YourProjectName"  # Replace with your Xcode project name
SCHEME_NAME="YourSchemeName"    # Replace with your scheme name
OUTPUT_FOLDER="output"        # Choose your desired output folder

# --- Derived Variables ---
BUILD_FOLDER="build"
ARCHIVE_PATH_IOS="$BUILD_FOLDER/$SCHEME_NAME-iOS"
ARCHIVE_PATH_SIMULATOR="$BUILD_FOLDER/$SCHEME_NAME-iOS_Simulator"
FRAMEWORK_NAME="$SCHEME_NAME.framework"
XCFRAMEWORK_NAME="$SCHEME_NAME.xcframework"
XCFRAMEWORK_PATH="$OUTPUT_FOLDER/$XCFRAMEWORK_NAME"

# --- Script ---
rm -rf "$BUILD_FOLDER" "$OUTPUT_FOLDER"

xcodebuild clean -project "$PROJECT_NAME.xcodeproj" -scheme "$SCHEME_NAME"

xcodebuild archive \
  -project "$PROJECT_NAME.xcodeproj" \
  -scheme "$SCHEME_NAME" \
  -configuration Release \
  -destination "generic/platform=iOS" \
  -archivePath "$ARCHIVE_PATH_IOS" \
  SKIP_INSTALL=NO \
  BUILD_LIBRARY_FOR_DISTRIBUTION=YES

xcodebuild archive \
  -project "$PROJECT_NAME.xcodeproj" \
  -scheme "$SCHEME_NAME" \
  -configuration Release \
  -destination "generic/platform=iOS Simulator" \
  -archivePath "$ARCHIVE_PATH_SIMULATOR" \
  SKIP_INSTALL=NO \
  BUILD_LIBRARY_FOR_DISTRIBUTION=YES

xcodebuild -create-xcframework \
  -framework "$ARCHIVE_PATH_IOS.xcarchive/Products/Library/Frameworks/$FRAMEWORK_NAME" \
  -framework "$ARCHIVE_PATH_SIMULATOR.xcarchive/Products/Library/Frameworks/$FRAMEWORK_NAME" \
  -output "$XCFRAMEWORK_PATH"
